Sport Fury doesn´t blink

Electrical & Ignition

  1. Stoffauge

    Stoffauge Member

    Messages:
    88
    Likes Received:
    9
    Joined:
    Feb 6, 2020
    Location:
    Germany
    Good morning,

    wondering my car just don´t like to blink. All lights and switches work. The blinker lighten up but no on off flashing they are just brighter till I switch off the blinker . Testet the relais already and it does click and the blink thing when tested just with 12v.

    Before I will look for the needle in a haystack I wanted to ask if somebody of you experts can just point on the problem with no effort.

    71 Sport Fury 383 4BBl AC

    Thanks,

    Fabian

  2. FURYGT

    FURYGT Senior Member

    Messages:
    2,969
    Likes Received:
    1279
    Joined:
    Mar 11, 2017
    Location:
    Iron Station, NC
    Have you replaced the flasher or switched it with the flasher for the hazard lights to see if you have a bad flasher?

    • Like Like x 2
  3. Stoffauge

    Stoffauge Member

    Messages:
    88
    Likes Received:
    9
    Joined:
    Feb 6, 2020
    Location:
    Germany
    Du you mean with flasher the switch I can operate with my left foot to activate high beam ? That thing works great . I didn’t replace any part because all the light stuff works/worked so far . Just no blinking

  4. CBODY67

    CBODY67 Old Man with a Hat

    Messages:
    5,832
    Likes Received:
    1322
    Joined:
    Mar 27, 2011
    Any bulbs which are not operating (i.e., burnt out)?

  5. commando1

    commando1 Old Man With a Hat on the Porch FCBO Gold Member

    Messages:
    35,164
    Likes Received:
    19700
    Joined:
    Mar 10, 2011
    Location:
    FUHOA Reservation, Sebring, Florida
    Check the obvious first.


    • Like Like x 5
  6. BIGBARNEYCARS

    BIGBARNEYCARS Senior Member FCBO Gold Member

    Messages:
    4,115
    Likes Received:
    2692
    Joined:
    Dec 10, 2012
    Location:
    SHADOW OF MOTHER'S PROVING GROUNDZ
    Like Commando just said: That little can will only hold so many Blinkz

    • Like Like x 1
  7. Stoffauge

    Stoffauge Member

    Messages:
    88
    Likes Received:
    9
    Joined:
    Feb 6, 2020
    Location:
    Germany
    One low beam is burned out but does that effect the blinker ?

  8. FURYGT

    FURYGT Senior Member

    Messages:
    2,969
    Likes Received:
    1279
    Joined:
    Mar 11, 2017
    Location:
    Iron Station, NC
    It should not. Under your dash somewhere in the wiring harness there are two flashers that will be round & a little bigger than a soda bottle plastic cap. Some are metal, some are plastic and some are square. If your hazard lights work switch the two of them and if your blinkers now work then you need to replace a flasher.

    • Agree Agree x 3
  9. Stoffauge

    Stoffauge Member

    Messages:
    88
    Likes Received:
    9
    Joined:
    Feb 6, 2020
    Location:
    Germany
    Okay I see . Both of these cYlindric things are called flasher . One for high beam one for blinker . That’s what I didn’t know .gonna try that right tomorrow and let you guys know .
    Thanks for that

  10. Stoffauge

    Stoffauge Member

    Messages:
    88
    Likes Received:
    9
    Joined:
    Feb 6, 2020
    Location:
    Germany
    Wait now I got you !

    if all 4 hazards work I don’t know just when I want to blink left the left side blinkers turn on but don’t Flash , so does the right side . Didn’t check if all 4 corners work at the same time .

    Check and switch flashers anyways ? Feel like now where it’s clearly explained it might something different causing the issue ?!

  11. LocuMob

    LocuMob Fluid Technician with a hat FCBO Gold Member

    Messages:
    12,622
    Likes Received:
    8365
    Joined:
    Oct 31, 2013
    Location:
    Blue Earth Mn
    Switch the round cylinder things. Now see if your blinkers flash.

    • Like Like x 1
  12. Stoffauge

    Stoffauge Member

    Messages:
    88
    Likes Received:
    9
    Joined:
    Feb 6, 2020
    Location:
    Germany
    Yes gonna do that right tomorrow. If it doesnt work will it mean both flashers are junk?

  13. LocuMob

    LocuMob Fluid Technician with a hat FCBO Gold Member

    Messages:
    12,622
    Likes Received:
    8365
    Joined:
    Oct 31, 2013
    Location:
    Blue Earth Mn
    That's what it would suggest.

  14. Big_John

    Big_John Illegitimi non carborundum FCBO Gold Member

    Messages:
    13,967
    Likes Received:
    8711
    Joined:
    May 21, 2013
    Location:
    Marcellus, NY
    No, I think the language barrier is the problem.

    The thing on the floor that controls the high and low beams is not a flasher. That's the dimmer switch.

    The turn signal flasher is under the dash and looks like this:

    ?q=tbn:ANd9GcT9_K910l4UfsZIxjw8jltM75G5WCXH_YGGDr9qyitPVaEo17M8DjB4p61PCTa-rtLA4kalOvqs&usqp=CAc.jpg

    There's another flasher for the hazard or 4-way flashers that looks the same. So there will be 2 of those under the dash. They operate independently of each other. When you find both of them, switch them and see if your problem with the turn signal (blinker) goes away and your hazard lights stop flashing.

    • Like Like x 3
  15. Stoffauge

    Stoffauge Member

    Messages:
    88
    Likes Received:
    9
    Joined:
    Feb 6, 2020
    Location:
    Germany
    Thank John, once more you nailed it 100%! Tomorrow I’ll let you know how it worked out . Dash is out so no problem to find both flashers very quick .

  16. Sport Fury 67

    Sport Fury 67 Member

    Messages:
    180
    Likes Received:
    144
    Joined:
    Mar 7, 2016
    Location:
    Buffalo Grove, IL
    There are two types of hazard flasher relays, one uses a bi-metallic mechanism [the metal can type] , the other is an electronic type [plastic body]. Typically there are two, one for the hazard (4-way) lights and one for the turn signals. Replace both at this time. The "heavy duty" is a good upgrade, it come in handy if you are ever going to pull a trailer. Here are some examples in the rock auto catalog. When I replaced mine in my 1978 Chrysler, I used the heavy duty electronic type.

    Let us know how it goes.

    1971 PLYMOUTH FURY 6.3L 383cid V8 Flasher | RockAuto

  17. Polara_500

    Polara_500 Senior Member FCBO Gold Member

    Messages:
    3,131
    Likes Received:
    1420
    Joined:
    Apr 17, 2011
    Location:
    MinnieSnowta
    One quick question here - since we now find out the dash is removed, have you absolutely verified the dash housings grounds?

    • Agree Agree x 1
  18. Stoffauge

    Stoffauge Member

    Messages:
    88
    Likes Received:
    9
    Joined:
    Feb 6, 2020
    Location:
    Germany
    The Ground spot on steering column is grounded through chassis and the flasher as part of the blinker and light circle I thought grounded through the ground of the lights and the Ground on the fenders ?! No?

  19. Big_John

    Big_John Illegitimi non carborundum FCBO Gold Member

    Messages:
    13,967
    Likes Received:
    8711
    Joined:
    May 21, 2013
    Location:
    Marcellus, NY
    Correct

  20. Stoffauge

    Stoffauge Member

    Messages:
    88
    Likes Received:
    9
    Joined:
    Feb 6, 2020
    Location:
    Germany
    Damnit just figured I can’t switch the flasher and check them because they are different . One two and one is three port and they don’t fit the other way round
