Transmission in reverse regardless of gear selection

Early C Bodies - The Slab Side Years

  1. Dixon

    Dixon New Member

    Messages:
    11
    Likes Received:
    2
    Joined:
    Mar 25, 2019
    Location:
    Summerfield, Fl
    I had an unusual occurrence today. Drove the 65 Newport wagon about 25 miles with no issues. Dropped off passengers and when I backed out of their driveway and shifted to "Drive" the tranny stayed in "Reverse". Goes into "Park" and "Neutral" but in any "movement" gear selected it's still in reverse. R, D, 2,1, my cars only goes reverse. I'm not so good at trannys so I am stumped on where to even start. Thanks all,

  2. Yeahrightgreer

    Yeahrightgreer Well-Known Member

    Messages:
    911
    Likes Received:
    524
    Joined:
    Oct 16, 2017
    Location:
    Camp Lejeune, NC
    I’m really just a spectator for this one


    Last edited: Mar 29, 2019
  3. rkrochen

    rkrochen Member

    Messages:
    175
    Likes Received:
    96
    Joined:
    Jun 29, 2015
    Location:
    Teulon, Manitoba
    Do you have park and neutral without any movement detected. If so there is likely an internal problem in the tranny. It is likely to do with the rear band staying engaged. On autos you need two components working together to make a movement. On Chryco trannies it is a combination of clutches and Bands. The common denominator here is the rear band. First thing I would do is pull the pan and see if the rear band is functional.

  4. Dixon

    Dixon New Member

    Messages:
    11
    Likes Received:
    2
    Joined:
    Mar 25, 2019
    Location:
    Summerfield, Fl
    Yes, in park it is in park. Neutral in neutral (will roll downhill). I was afraid it may be internal. Thank you, rkrochen.

  5. furious70

    furious70 Member

    Messages:
    186
    Likes Received:
    54
    Joined:
    Aug 18, 2018
    Location:
    Chitown
    Since neutral works it's hard to imagine linkage broke or slipping not allowing it to move into drive, but the easiest thing to do first is verify the linkage moves freely and completely

  6. rkrochen

    rkrochen Member

    Messages:
    175
    Likes Received:
    96
    Joined:
    Jun 29, 2015
    Location:
    Teulon, Manitoba
    The only thing that could be repaired externally is if the servo is stuck. Most likely need to remove the tranny and overhaul. If it is a high miler I would just rebuild.

  7. Davea Lux

    Davea Lux Senior Member FCBO Gold Member

    Messages:
    3,385
    Likes Received:
    847
    Joined:
    Mar 27, 2017
    Location:
    Cornelius Or
    As noted, the servo is probably stuck. Pull the pan, if the pan is full of black gunk you are headed to a rebuild. Sometimes the servo piston can get stuck from the piston getting wedged in the bore, usually because of excessive wear. FSM shows how to disassemble the servo. If is is getting stuck, it is time to replace the servo assuming the rest of the transmission is not toast.

    Dave

    Last edited: Mar 29, 2019
  8. Dixon

    Dixon New Member

    Messages:
    11
    Likes Received:
    2
    Joined:
    Mar 25, 2019
    Location:
    Summerfield, Fl
    Thanks for the advice, all. I'm thinking I'll just get it to a shop and have it rebuilt. I really have no definitive idea what the mileage really is or how it's been treated the last 54 years. I will update when repaired.

    • Like Like x 1
    • Thanks! Thanks! x 1
    • Agree Agree x 1
  9. Dixon

    Dixon New Member

    Messages:
    11
    Likes Received:
    2
    Joined:
    Mar 25, 2019
    Location:
    Summerfield, Fl
    And the plot thickens (doesn't it always?). Went to the other house (1/2 mile away), started her up, and she drove fine. Additional info for the repair shop Monday in any event. Stay tuned.

  10. CBODY67

    CBODY67 Senior Member

    Messages:
    3,412
    Likes Received:
    729
    Joined:
    Mar 27, 2011
    Possible verification of a stuck servo piston that freed-up after everything cooled down?

    CBODY67

    • Agree Agree x 1
  11. Dixon

    Dixon New Member

    Messages:
    11
    Likes Received:
    2
    Joined:
    Mar 25, 2019
    Location:
    Summerfield, Fl
    Quite possible, I'd say. Something cooled down and freed up. Thanks.

  12. CBODY67

    CBODY67 Senior Member

    Messages:
    3,412
    Likes Received:
    729
    Joined:
    Mar 27, 2011
    Now wondering if some atf cleaner additive might be something to think about adding, then driving it a bit more? If nothing else, it'll get things cleaner for the rebuild . . . although the shop should pull the case and such apart and pressure clean them in some sort of cleaning machine.

    Just some thoughts,
    CBODY67

  13. rkrochen

    rkrochen Member

    Messages:
    175
    Likes Received:
    96
    Joined:
    Jun 29, 2015
    Location:
    Teulon, Manitoba
    I’m not a fan of additives. If it was mine I would remove the pan and take the servo apart. See if there is anything visible such as worn sealing ring or bore wear. Check the filings in the pan to see if they are excessive. Adding an additive won’t help the rebuilder as he needs to thoroughly clean things anyways. Usually trannies are easy to clean.

  14. Dixon

    Dixon New Member

    Messages:
    11
    Likes Received:
    2
    Joined:
    Mar 25, 2019
    Location:
    Summerfield, Fl
    Just an update everyone. It has acted funky a couple more times i.e. no reverse...put in Park...then reverse...works. Anyway, I had my shop, while they were doing other work, drain fluid (looked pretty good), check pan (no remarkable shavings etc.), new fluid and filter. Drove her home (about 20 miles)...stuck in reverse again, Cooled down an hour and works. I think a remanufactured tranny is in her near future. Can't be trusted. Thanks for the advice everyone. I'll let y'all know.

  15. twostick

    twostick Senior Member

    Messages:
    1,545
    Likes Received:
    632
    Joined:
    Dec 13, 2012
    Location:
    Beautiful Downtown Roebuck Ont.
    Just replace the servo. If you had done it when you dropped the pan it would have added an hour to the job and $75 for parts.

    Randy

    It's still worth a shot for what little it costs vs a full rebuild. If the trans operates properly otherwise and the fluid looked good with no shrapnel in the pan, I wouldn't mess with it. Install servo kit, adjust the bands and call it a day.

    Kevin

    • Agree Agree x 1
  16. Dixon

    Dixon New Member

    Messages:
    11
    Likes Received:
    2
    Joined:
    Mar 25, 2019
    Location:
    Summerfield, Fl
    Thanks. We'll try that.

  17. twostick

    twostick Senior Member

    Messages:
    1,545
    Likes Received:
    632
    Joined:
    Dec 13, 2012
    Location:
    Beautiful Downtown Roebuck Ont.
    There's another company called Sonnax that makes a billet kit that's a lot cheaper but it isn't as pretty as Randy's. Don't know if it matters for your application if one is any better.

    Sonnax Chrysler A727 Reverse Servo Piston A518 46RH 46RE

    Kevin

    • Agree Agree x 1
  18. rkrochen

    rkrochen Member

    Messages:
    175
    Likes Received:
    96
    Joined:
    Jun 29, 2015
    Location:
    Teulon, Manitoba
    It’s unfortunate that you didn’t take the Servo out while you had the pan off. I like the replacement mentioned in the previous reply. Get one and install it, almost guarantee it will resolve the problem. For the cost it’s worth the try. While your at it adjust the front band as well.

  19. 70bigblockdodge

    70bigblockdodge Old Man with a Hat FCBO Gold Member

    Messages:
    10,712
    Likes Received:
    4066
    Joined:
    Jan 19, 2013
    Location:
    Avonmore Pa.
    Adjust the low reverse band, it letting the servo pop out too far.
    Don't go back to that shop.
    Customer comes in saying car was stick in reverse and all you do is R&R the filter and fluid?
    Find a new shop, those people are lazy and not that bright.
    Anyone who pulls the pan on a Chrysler trans and does not adjust the low reverse band does not know what they are doing. Go find another shop.

    • Agree Agree x 3
  20. Dixon

    Dixon New Member

    Messages:
    11
    Likes Received:
    2
    Joined:
    Mar 25, 2019
    Location:
    Summerfield, Fl
    Just closing the loop on this entire thread. On advice from an actual transmission shop, I took the leap and had the tranny removed and "remanufactured". What a difference. Smooth but firm shifts, nothing funky yet. I think it was money well spent. Thanks all for the advice. Peace.....

    • Like Like x 1
